B-2
SUPERSERVER 7047R-TRF USER'S MANUAL
Serverboard
X9DRi-F (Extended ATX form factor)
Dimensions: 12.00" (L) x 13.00" (W) (304.80 mm x 330.20 mm)
Chassis
SC745TQ-R920B, tower/4U mini-tower
Dimensions (as tower): (WxHxD) 7 x 19 x 27 in. (178 x 483 x 686 mm)
Weight
Gross (Bare Bone): 70 lbs. (31.8 kg.)
System Cooling
Three (3) 8-cm system cooling fans
Two (2) 8-cm rear exhaust fans
One (1) air shroud
System Input Requirements
AC Input Voltage: 100-230V AC auto-range
Rated Input Current: 9A - 4A
Rated Input Frequency: 50 to 60 Hz
Platinum: 90+ (Platinum Level)
Power Supply
Rated Output Power: 920 Watt (Part# PWS-741P-1R)
Rated Output Voltages: +12V (12A), +5Vsb (5A)
Operating Environment
Operating Temperature: 0º to 60º C (32º to 140º F)
Non-operating Temperature: -40º to 70º C (-40º to 158º F)
Operating Relative Humidity: 20% to 95% (non-condensing)
Non-operating Relative Humidity: 5 to 95% (non-condensing)
