Chapter 2: Server Installation
2-7
Installing the Rack Rails
Determine where you want to place the SuperServer 7047R-TRF in the rack. (See
Rack and Server Precautions in Section 2-3.) Position the fi xed rack rail/sliding rail
guide assemblies at the desired location in the rack, keeping the sliding rail guide
facing the inside of the rack. Screw the assembly securely to the rack using the
brackets provided. Attach the other assembly to the other side of the rack, making
sure both are at the exact same height and with the rail guides facing inward.
Figure 2-3. Installing the Rails to the Chassis
