Supero SUPERSERVER 7047R-TRF User Manual

6-8
SUPERSERVER 7047R-TRF USER'S MANUAL
Storage Module
If the SuperServer 7047R-TRF is to be used in a rack confi guration, you must turn
the storage module 90 degrees. This can be done before, during, or after setup.
Rotating the Storage Module
1. Open the chassis cover.
2. Disconnect any cables from the storage module to any components in the
chassis.
3. Push the storage module release lever to unlock the storage module.
4. Grasp the external edges of the storage module and pull it from the chassis.
5. Turn the storage module 90 degrees (as illustrated).
6. Reinsert the module into the chassis and reconnect the cords.
Storage Module
Release Lever
Storage Module
Figure 6-7. Rotating the Storage Module
