Chapter 3: System Interface
3-1
Chapter 3
System Interface
3-1 Overview
The control panel on the SUPERSERVER 7047R-TRF has several LEDs and two
buttons. There are also two LEDs on each SATA drive carrier. These LEDs keep
you constantly informed of the overall status of the system and the activity and
health of specifi c components.
3-2 Control Panel Buttons
There are two push-buttons located on the front of the chassis: a power on/off
button and a reset button.
Power
This is the main power button, which is used to apply or turn off the main system
power. Turning off system power with this button removes the main power but keeps
standby power supplied to the system.
Reset
Use the reset button to reboot the system.
