5-26
SUPERSERVER 7047R-TRF USER'S MANUAL
Onboard Power LED
An Onboard Power LED is located
at LE1 on the motherboard. When
this LED is on, the system is on. Be
sure to turn off the system and unplug
the power cord before removing or
installing components. See the tables
at right for more information.
Onboard PWR LED Indicator
LED Settings (LE1)
LED Color Defi nition
Off System Off (PWR cable not
connected)
Green System On
Green: Flashing
Quickly
ACPI S1 State
BMC Heartbeat LED
A BMC Heartbeat LED is located at
DM1 on the motherboard. When DM1 is
blinking, BMC functions normally. See
the table at right for more information.
BMC Heartbeat LED
Status (DM1)
Color/State Defi nition
Green: Blinking BMC: Normal
Serial ATA Ports
There are six Serial ATA Ports
(I-SATA0~I-SATA 5) located on the
motherboard. I-SATA 0/1 support
SATA 3.0 and I-SATA 2~5 are SATA
2.0 ports These ports provide serial-
link signal connections, which are
faster than the connections of Parallel
ATA. See the table on the right for pin
defi nitions.
5-11 SATA Drive Connections
SATA Ports Pin Defi nitions
(SATA0-SATA3)
Pin # Defi nition Pin # Defi nition
1 Ground 5 RX_N
2 TX_P 6 RX_P
3 TX_N 7 Ground
4 Ground
