SUPERSERVER 7047R-TRF USER'S MANUAL
5-8 Connector Defi nitions
ATX Power 24-pin Connector
Pin Defi nitions (JPWR3)
Pin# Defi nition Pin # Defi nition
13 +3.3V 1 +3.3V
14 -12V 2 +3.3V
15 COM 3 COM
16 PS_ON 4 +5V
17 COM 5 COM
18 COM 6 +5V
19 COM 7 COM
20 Res (NC) 8 PWR_OK
21 +5V 9 5VSB
22 +5V 10 +12V
23 +5V 11 +12V
24 COM 12 +3.3V
12V 8-pin PWR Connector
Pin Defi nitions (JPWR1/2)
Pins Defi nition
1 through 4 Ground
5 through 8 +12V
Required Connections
Power Connectors
A 24-pin main power supply
connector(JPWR3) and two 8-pin
CPU PWR connectors (JPWR1/2)
are located on the motherboard.
These power connectors meet the SSI
EPS 12V specifi cation. These power
connectors must also be connected to
your power supply. See the table on
the right for pin defi nitions.
Warning: To provide adequate
power supply to the motherboard,
be sure to connect the 24-pin ATX
PWR (JPWR3) and two 8-pin PWR
connectors (JPWR1, JPWR2) to the
power supply. Failure to do so will void
the manufacturer warranty on your
power supply and motherboard.
PW_ON Connector
The Power Button connection is
located on pins 1 and 2 of JF1.
Momentarily contacting both pins will
power on/off the system. This button
can also be confi gured to function as
a suspend button (with a setting in the
BIOS - See Chapter 5). To turn off the
power when the system is in suspend
mode, press the button for 4 seconds
or longer. Refer to the table on the right
for pin defi nitions.
Power Button
Pin Defi nitions
(JF1)
Pin# Defi nition
1 PW_ON
2 Ground
