SUPERSERVER 7047R-TRF USER'S MANUAL
3-3 Control Panel LEDs
The control panel located on the front of the SC745 chassis has six LEDs that
provide you with critical information related to different parts of the system. This
section explains what each LED indicates when illuminated and any corrective
action you may need to take.
2
1
Power
Indicates power is being supplied to the system's power supply. This LED should
normally be on when the system is operating.
HDD
Indicates SATA drive activity when fl ashing.
NIC1
Indicates network activity on LAN1 when fl ashing.
NIC2
Indicates network activity on LAN2 when fl ashing.
