Supero SUPERSERVER 7047R-TRF User Manual

Chapter 5: Advanced Serverboard Setup
5-3
2. Press the second load lever labeled 'Close 1st' to release the load plate that
covers the CPU socket from its locking position.
OPEN 1st
OP
EN
1s
t
WARNING!
WARNING!
OPEN 1st
OPEN 1st
WARNING!
WARNING!
Press down on Load the Lever
labeled 'Close 1st'
Pull lever away
from the socket
3. With the lever labeled 'Close 1st' fully retracted, gently push down on
the 'Open 1st' lever to open the load plate. Lift the load plate to open it
completely.
Gently push down to pop the
load plate open.
OPEN 1st
OPEN 1st
WARNING!
WARNING!
WARNING!
WARNING!
4. Using your thumb and the index fi nger, remove the 'WARNING' plastic cap
from the socket.
WARNING!
