Chapter 1: Overview
1-5
JPME1 ME Recovery Pins 2-3 (Normal)
X10DAi/X10DAC/X10DAX Jumpers
Jumper Description Default Setting
JBT1 Clear CMOS See Chapter 2
JI
I2
C1/JI
I2
C2 SMBus to PCI-E Slots Pins 2-3 (Normal)
JPL1 GLAN1 & GLAN2 Enable/Disable Pins 1-2 (Enabled)
JPL2 GLAN2 Enable/Disable Pins 1-2 (Enabled)
JPME2 ME (Manufacture) Mode Select Pins 1-2 (ME Mode)
JPS1 (X10DAC Only) SAS Enable Pins 1-2 (Enabled)
JWD1 Watch Dog Pins 1-2 (Reset)
X10DAi/X10DAC/X10DAX Connectors
Connectors Description
Audio_FP (JA1) Audio Connector for Front Access
JAudio1 7.1 HD (8-channel High-Denition) Audio Connector
BT1 Onboard CMOS Battery (See Chapter 3 for Used Battery Disposal)
CPU1 Slot1/Slot3 PCI-E 3.0 x16 Slots
CPU2 Slot5 PCI-E 3.0 x16 Slot (This slot is available when CPU2 is installed.)
CPU2 Slot2 PCI-E 3.0 x8 Slot (This slot is available when CPU2 is installed.)
CPU2 Slot4 PCI-E 3.0 x8 Slot (The slots are available when CPU2 is installed.)
PCH Slot6 PCI-E 2.0 x4 in x8 Slot
FAN1-7, FANA CPU/System Fan Headers
J24 ATX 24-Pin Power Connector (See Warning on Page 1-6.)
JD1 Speaker/Power LED Indicator
JF1 Front Panel Control Header
JL1 Chassis Intrusion
JPI
I2
C1 Power Supply SMBbus I
2
C Header
JPWR1/JPWR2 12V 8-Pin Power Connectors (See Warning on Page 1-6.)
JSD1/JSD2 SATA DOM (Device_On_Module) power connection head-
ers 1/2 1/2
JSPDIF_In SPDIF_(Sony/Philips Digital Interface)_In Header
JSPDIF_Out SPDIF_(Sony/Philips Digital Interface)_Out Header
JTBT1 GPIO (General-Purpose I/O) Header for Thunderbolt Add-on Card
JTPM1 TPM (Trusted Platform Module)/Port 80 Header
LAN1/LAN2 G-bit Ethernet Ports 1/2
