X10DAi/X10DAC/X10DAX Motherboard User's Manual
Warning: To prevent damage to the power supply or motherboard, please use a power
supply that contains a 24-pin and two 8-pin power connectors. Be sure to connect
these power supply connectors to the 24-pin power connector (J24) and two 8-pin
power connectors (JPWR1, JPWR2) on the motherboard. Failure in doing so will void
the manufacturer warranty on your power supply and motherboard.
I-SATA0-9 Serial_Link ATA Connections 0-9 supported by Intel PCH (I-SATA4/5
support Supermicro SuperDOMs [Devices-on-Module]
with power pins built-in)
SAS 0-3, 4-7 (JS2)
(X10DAC Only)
Serial_Link SCSI Connections 0-3, 4-7 supported by LSI SAS Control-
ler
SP1 Onboard Buzzer (Internal Speaker)
STBY1 Standby Power Header
T-SGPIO 1/2/3 Serial-Link General_Purpose IO Headers 1/2/3
USB 5/6 (3.0) Rear USB 3.0 Ports 5/6
USB 7/8 (3.0) Rear USB 3.0 Ports 7/8
USB 9/10 (3.0) Front-accessible USB 3.0 Connections 9/10
USB 0/1 (2.0) Rear USB 2.0 Connections 0/1
USB 2/3 (2.0) Front-accessible USB 2.0 Connections 2/3
USB 4 (2.0) Type A USB 2.0 Connector USB 4
X10DAi/X10DAC/X10DAX LED Indicators
LED Description State Status
DS2 (X10DAC Only) SAS Heartbeat LED Green: Blinking SAS: Normal
LE2 Standby PWR LED Green: On SB Power On
