4-4
Supermicro X10SRA/X10SRA-F Motherboard User’s Manual
By default, some advanced menu options are hidden from displa
y
.
Clicking Expert Mode ON or OFF will displa
y or hide these options from
the menu. In this chapter
, all Expert Mode option items are
bold and
underlined
.
Expert Mode
The Save
and Load icon brings up a pop-up menu th
at enables the user
to choose from different sa
ving options at the end of the
session.
Save &
Load
75
77
