20
i
EN
7. Flush mounting
9.
Screw the belt winder tightly.
10.
Open the operating panel.
Slide the belt winder into the belt box
and screw it tight using the assembly
screws provided.
IMPORTANT
Pay attention to connecting cables.
Feed both connecting cables through
the grooving of the mounting frame
on the bottom side of the belt winder,
as described on page 18.
The operating panel can be opened by
pressing lightly and levering open with
a at screwdriver.
