22
i
EN
7. Flush mounting
13.
Optionally, mount the belt adapter.
14.
Attach the screw cover.
Only required with mini belt (15 mm
width), otherwise continue with point
14. For an optimum belt guide to be
achieved for mini belts, the provided
belt adapter must be pushed into the
reel compartment after feeding in
the belt.
Press the bottom screw cover into
the mounting frame and close the
reel compartment by pressing the
operating panel closed.
