Superscope PSD340 - Table of Contents; Specifications

Table of Contents
- 3 -
Warning ..................................................................2
Safety Instructions .................................................2
Table of Contents ..................................................3
Specifications .....................................................3
Introduction .....................................................4
Package Contents ...................................................4
Features .................................................5
Top of Unit......................................................5
Front of Unit......................................................8
Remote Control...............................................9
Back of Unit.........................................................10
Set Up ........................................................11
Powering Up ......................................................11
Setting Up Speakers ............................................11
Headphones or Built-In Speaker....................11
External Speakers......................................11
Setting Up Instruments, Mics, & Other Sound Sources ....11
Microphones....................................11
Internal Microphone.....................................12
Instruments........................................12
Line Level Sources..............................12
Setting Levels...........................................12
Music Practice & CD Playback ....................................13
How to Use the Tuner .......................................13
How to Use the Metronome .............................14
Playing a CD ...................................................15
Selecting A-B Practice Loops ............................15
Changing Key and Tempo ........................15
Voice Reduction ..........................................16
Recording ......................................................17
Making a Live Recording ...................................17
Minute Track Mode..............................................18
Recording from a Digital Input ................18
Adding Reverb or Delay ........................................18
Right & Left Channel Mix ....................................18
How to Record with CD .................................19
Program a Playlist ....................................19
Recording Key, Tempo and VR Changes .........19
Activating “Record with CD” Mode............19
How to Record a Song Segment ..............................20
How to Copy an Existing CD ............................20
Copying from an External Source .............................20
How to Finalize a Disc .......................................21
How to Unfinalize a CD-RW disc.......................21
How to Erase a CD-RW...................................21
Menus .......................................................................22
Play Menu .........................................22
Record Menu .........................................23
Stop Menu ................................................24
Troubleshooting .......................................................25
Further Information ...................................................27
Warranty......................................................30
Topic Page
Specifications
General
System........................ Compact Disc Digital Audio (CD-DA)
Number of channels...............................................2 (stereo)
Applicable discs.......................................CD, CD-R, CD-RW
Power requirements:
/U1B...........................................120V 60Hz,21W
/N1B............................................230V 50Hz,21W
/K1B............................................220V 50Hz,21W
Dimensions (maximum)
Width.......................................11.625 inches (296 mm)
Height......................................... 3.635 inches (92 mm)
Depth...........................................8.75 inches (222 mm)
Weight...............................................7 pounds (3.2 Kg)
Audio
ADC..............................24 Bit Resolution 64x Oversampling
DAC.......................................................... 20 Bit Resolution
Overall frequency response.............................20Hz - 20kHz
CD-R drive output
Playback S/N................................................................90dB
Playback Dynamic Range.............................................90dB
Playback Total Harmonic Distortion.............................0.01%
Output Voltage/Impedance (Line Output)...............2.0V/2.2K
CD drive output
Playback S/N................................................................90dB
Playback Dynamic Range..............................................90dB
Playback Total Harmonic Distortion............................0.01%
Output Voltage ....................................................2.0V/2.2K
MIC/LINE analog input
LINE level
S/N .....................................................................85dB
THD...................................................................0.05%
Input Sensitivity/Impedance...........................500mV/6K
MIC level
S/N .....................................................................70dB
THD ....................................................................0.1%
Input Sensitivity/Impedance ...........................3.0mV/6K
AUX analog input
S/N ....................................................................85dB
THD ..................................................................0.01%
Input Sensitivity/Impedance ...................... 500mV/50K
Digital Input
Sample rate .................................32kHz/44.1kHz/48kHZ
Digital Output
Output Level/Impedance ..........................0.5Vp-p/75Ω
Headphone Output (10% THD)
Level/Impedance........................................30mW/32Ω
Speaker Output (10% THD)
Level/Impedance ........................................... 2.0W/8Ω
Operating Temperature .........+5° C -+35°C (41°F -95°F)
