NICE3000 User Manual Function parameter description
109
If E21 alarms in the starting, check that whether the identication result parameters F1-06 and
F1-08 are correct t. If its ensured that the wiring of motor and PG card isnt changed, you
can directly input the two data recorded after the rst identication, or re-recognize the pulse
wheel encoders position angle.
Recommendation: Recognize the encoders position several times, compare with the da
ta of
F1-06, if the error is without ±5°, which indicates errors exist in the encoder or wiring.
Running trial
After the encoders position identification, do the running trials with no load (the traction
machine with no iron wires) before the recovery. The mode of running trial is recommended to
adopt inspection up and down buttons, at the moment, deal with the safety circuit and door lock
circuit
according to the system condition. In the running trial course, the following two points
need specially care:
If the direction of the traction machine is corresponding to the reality (Up and Down), if not,
it needs to adjust the NICE 3000 wiring outputting to the motor, re-recognize the encoders
position.
Whether the traction machines forward and reversal running are stable and no noise;
because o
f no load in the traction machine, the current will be extremely small and NICE 3000
displays the current lower than 1A.
After the confirmation of the two points, NICE 3000 have recorded the traction machines
encoder position correctly into F1-06 (Users can record it down for the later using), and it can
do the normal control. The following step is adjusting according to the lifts normal adjustin
g
course. Due to the different features of synchronous motor and asynchronous motor, user can
reduce the speed loop P1 gain of F2 group when in use.
Note: After the lift is using normally, adjust the motor wiring and encoder wiring will both cause
the lift cant be normally used.
The usually used parameters:
Shaft parameter auto-tuning is used to record the position of shafts opening and closing
(In
cluding leveling switch and force reducer switch). Requirements are as follows:
Encoder and leveling feedback is normal; the switch of the shaft is installed well.
The lift is in the ground oor, forced deceleration switch operation.
The lift is in examination and can check running.
The lowest and highest oors are set correctly.
NICE 3000 is not in the error alarming state.
Note: shaft auto-tuning can
also be realized by the small keyboards on the main control panel.
Two floor auto-tuning needs the lift run under the first leveling which means theres one
leveling sensor under the leveling plate..
F1-12
Encoder pulse number per rotation Default 1024 Min. Unit 1
Setting Range 010000
