NICE3000 User Manual Function parameter description
147
Code Display Code Display
00 0 10 A
01 1 11 B
02 2 12 G
03 3 13 H
04 4 14 L
05 5 15 M
06 6 16 P
07 7 17 R
08 8 18 -
09 9 19 No display
20 12 21 13
22 23 22 No display
For example:
Actual oor
Required
displaying
Higher 2 bit setting Lower 2 bit setting
Corresponding
function code setting
Basement 1 -1
- corresponding
code 18
1
corresponding code
01
1801
Floor 1 G
No display,
corresponding
code19
G
corresponding code
12
1912
Floor 2 2
No display,
corresponding code
19
2
corresponding code
02
1902
Floor 14 13A
13,
corresponding code
21
A
corresponding code
10
2110
FE-31 cant only set the oor 31 hall displaying content, but also can express the opposite
door plural selection hall call function. When FE-31 setting value isnt less than 10, it
expresses the oor 31 hall corresponding displaying content. If the highest oor is less than
oor 29(F6-00<29) when FE-31 setting value is less than 10, it expresses that one oor below
floor 10 is double door and double hall displaying. Set
the on-off switch address of back
door hall call panel as 31, the system can differentiate front door and back door. At this time,
FE-31 setting parameter expresses the corresponding oor of the hall call panel on-off switch
setting31.
For example: the highest oor is oor 10, the lowest oor is oor 1, and oor 2 is the double
door with hall call displaying panel and button. At this time, set FE-
31 as 2. In this way, the
two display panels of on-off switch setting address 31 and 2 both can be used for the hall
call displaying panel of oor 2. But in this condition, the two hall calls have the same calling
function, cant control front door and back door all by itself.
