NICE3000 User Manual Function parameters tables
85
Function
Code
Name Setting Range Min. Unit Default
Modifi-
cation
F2-10
Lift Running
direction
0:same direction
1:reverse running direction, reverse position
impulse direction
2:same running direction, reverse impulse
direction
3:reverse running direction, same impulse
direction
1 0 ☆
F3 Running Control Parameters
F3-00 Start speed 0.000～0.030m/s 0.001m/s 0.010m/s ★
F3-01 Time keeping 0.000～0.500s 0.001s 0.150s ★
F3-02 Acceler
ation 0.200～2.000m/s
2
0.001m/s
2
0.600m/s
2
★
F3-03
Inexion
speedup time 1
0.300～4.000s 0.001s 2.500s ★
F3-04
Inexion
speedup time 2
0.300～4.000s 0.001s 2.500s ★
F3-05 Deceleration 0.200～2.000m/s
2
0.001m/s
2
0.600m/s
2
★
F3-06
Inexion slow-
down time 1
0.300～4.000s 0.001s 2.500s ★
F3-07
Inexion slow-
down time 2
0.300～4.000s 0.001s 2.500s ★
F3-08
Special
deceleration
0.500～2.000m/s
2
0.001m/s
2
0.900m/s
2
★
F3-09
Pre-distance of
stop
0～90.0mm 0
.1mm 0.0mm ★
F3-10
Re-leveling
speed
0.000～0.080 m/s 0.001 m/s 0.040m/s ★
F3-11
Speed of slow
running
0.100～0.630 m/s 0.001 m/s 0.250m/s ★
F3-12
Switching
position of the
NO.1 up force
reducer
0.00～300.00m 0.01m 0.00m ★
F3-13
Switching
position of the
NO.1 down
force reducer
0.00～300.00m 0.01m 0.00m ★
F3-14
Switching
position of the
NO.2 up force
reducer
0.00～300.00m 0.01m 0.00m ★
F3-15
Switching
position of the
NO.2 down
force re
ducer
0.00～300.00m 0.01m 0.00m ★
F3-16
Switching
position of the
NO.3 up force
reducer
0.00～300.00m 0.01m 0.00m ★
F3-17
Switching
position of the
NO.3 down
force reducer
0.00～300.00m 0.01m 0.00m ★
F3-18
Output time of
starting zero
speed
0.000～1.000s 0.001s 0.200s ★
F3-19
Time-lag of
curve running
0.000～1.000s 0.001s 0.200s ★
