4-2 FUEL AND LUBRICATION SYSTEM
FUEL TANK
REMOVAL
Remove the seat and side covers. ( 6-2)
Turn the fuel valve to the “OFF” position.
Disconnect the fuel hose.
Gasoline is highly flammable and explosive.
Keep heat, sparks, and flames away from gasoline.
Remove the fuel tank.
REMOUNTING
Remount the fuel tank in the reverse order of removal.

Table of Contents

Questions and Answers:

Suzuki drz 400E Specifications

General IconGeneral
Displacement398 cc
Compression Ratio12.2:1
IgnitionElectronic ignition (CDI)
Transmission5-speed constant mesh
Rear SuspensionLink type, coil spring, oil damped
Front Tire80/100-21
Rear Tire110/100-18
Engine Type4-stroke, DOHC
Bore x Stroke90.0 mm x 62.6 mm
Fuel SystemMikuni BSR36 carburetor
Front BrakesDisc
Rear BrakesDisc
Fuel Tank Capacity10.0 L (2.6 US gallons)
Overall Width825mm (32.5 inches)
Ground Clearance315 mm (12.4 in)
Seat Height935 mm (36.8 in.)
Curb Weight138 kg (304 lbs)
Dry Weight119 kg (262 lbs.)
