Suzuki drz 400E Service Manual

ELECTRICAL SYSTEM 7-31
RECHARGING OPERATION
Measure the battery voltage using the multi circuit tester or
digital volt meter. If the voltage reading is less than the 12.6 V
(DC), recharge the battery with a MF battery charger.
When recharging the battery, remove the battery from
the motorcycle.
Recharging time: 0.65 A for 5 to 10 hours.
Do not attempt boost charging under any circum-
stances.
After recharging, wait at least 30 minutes and then measure
the battery voltage using the multi circuit tester. If the battery
voltage is less than 12.6 V, recharge the battery again. If the
battery voltage is still less than 12.6 V after recharging, re-
place the battery with a new one.
When a battery is left unused for a long time, its voltage needs
to be regularly measured. When the motorcycle is not used for
more than one month (especially during the winter season),
measure the battery voltage at least once a month.

Suzuki drz 400E Specifications

General

Displacement	398 cc
Compression Ratio	12.2:1
Ignition	Electronic ignition (CDI)
Transmission	5-speed constant mesh
Rear Suspension	Link type, coil spring, oil damped
Front Tire	80/100-21
Rear Tire	110/100-18
Engine Type	4-stroke, DOHC
Bore x Stroke	90.0 mm x 62.6 mm
Fuel System	Mikuni BSR36 carburetor
Front Brakes	Disc
Rear Brakes	Disc
Fuel Tank Capacity	10.0 L (2.6 US gallons)
Overall Width	825mm (32.5 inches)
Ground Clearance	315 mm (12.4 in)
Seat Height	935 mm (36.8 in.)
Curb Weight	138 kg (304 lbs)
Dry Weight	119 kg (262 lbs.)
