9-10 DR-Z400EY (E-24 MODEL)
ITEM STANDARD/SPECIFICATION LIMIT
Rear wheel travel 295
(11.6)
———
Swingarm pivot shaft runout 0.3
———
(0.01)
ELECTRICAL
ITEM SPECIFICATION NOTE
Spark plug
Type
DENSO: U24ESR-N
NGK: CR8E
Gap
0.7 – 0.8 mm
(0.028 – 0.031 mm)
Spark performance Over 8 mm (0.3 in) at 1 atm.
Ignition coil resistance
Primary 0.1 – 1.0 Ω
Terminal –
Ground
Secondary 12 – 20 kΩ
Plug cap –
Terminal
Ignition coil primary peak voltage More than 150 V + : B/W,
- : B/Y
Generator coil resistance Charging 0.50 – 1.25 Ω Y – Y
Signal coil 0.05 – 0.20 Ω B – W
Pick-up coil 390 – 600 Ω G – Bl
Pick-up coil peak voltage More than 5.0 V + : Bl, - : G
Signal coil peak voltage More than 1.4 V + : B, - : W
Generator no-load voltage
More than 75 V (AC) at 5 000 r/min. Y – Y
(when engine is cold)
Regulated voltage 13.5 – 15.0 V at 5 000 r/min.
Generator Max. output 200 W at 5 000 r/min.
Starter relay resistance 3 – 5 Ω
Battery Type designation GT7B-4
Capacity 12 V 23.4 kC (6.5 Ah)/10 HR
Fuse size * 20 A
WATTAGE Unit: W
ITEM SPECIFICATION
Headlight HI * 60
LO * 55
Brake light/Taillight * 21/5
Turn signal light * 21
Speedometer light * LED
Neutral indicator light * 2
High beam indicator light * 2
Turn signal indicator light * 2
