1F-13 Engine Cooling System:
Specifications
Service Data
B649G11607002
Oil Pump
Oil
Tightening Torque Specifications
B649G11607003
NOTE
The specified tightening torque is also described in the following.
“Engine Cooling System Components: ”
“Oil Cooler and Oil Cooler Hose Components: ”
“Oil Cooler and Oil Cooler Hose Construction: ”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque Specifications: in Section
0C”.
Special Tools and Equipment
Recommended Service Material
B649G11608001
NOTE
Required service material is also described in the following.
“Engine Cooling System Components: ”
“Oil Cooler and Oil Cooler Hose Components: ”
“Oil Cooler and Oil Cooler Hose Construction: ”
Item Standard Limit
Oil pump reduction ratio 1.703 (72/46 x 37/34) —
Oil pressure (at 60 °C, 140 °F)
Above 300 kPa (3.0 kgf/cm
2
, 43 psi)
Below 600 kPa (6.0 kgf/cm
2
, 85 psi)
at 3 000 r/min.
—
Item Specification Note
Engine oil type SAE 10W-40, API SF/SG or SH/SJ with JASO MA
Engine oil capacity
Change 3 300 ml (3.4/2.9 US/lmp qt)
Filter change 3 500 ml (3.6/3.0 US/lmp qt)
Overhaul 4 600 ml (4.9/4.0 US/lmp qt)
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Oil cooler hose connecting bolt 10 1.0 7.0 )
Oil cooler mounting bolt 10 1.0 7.0 )
Oil cooler hose bracket bolt 10 1.0 7.0 )
Oil cooler hose union bolt 28 2.8 20.0 )
Engine Cooling hose mounting bolt 10 1.0 7.0 )
Oil pump mounting bolt 10 1.0 7.0 )
Oil pressure regulator 28 2.8 20.0 )
Material SUZUKI recommended product or Specification Note
Thread lock cement Thread Lock Cement 1342 or
equivalent
P/No.: 99000–32050 )
Thread Lock Cement Super 1322 or
equivalent
P/No.: 99000–32110 )
