Suzuki GSF1200S User Manual

Rear Brakes: 4C-9
Specifications
Service Data
B649G14307004
Brake
Unit: mm (in)
Oil
Tightening Torque Specifications
B649G14307005
NOTE
The specified tightening torque is also described in the following.
“Rear Brake Components: ”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque Specifications: in Section
0C”.
Item Standard Limit
Brake disc thickness Rear 4.8 – 5.2 (0.189 – 0.205) 4.5 (0.18)
Brake disc runout — 0.30 (0.012)
Brake caliper cylinder bore Rear 38.180 – 38.256 (1.5031 – 1.5061) —
Brake caliper piston diameter Rear 38.098 – 38.148 (1.4999 – 1.5019) —
Item Specification Note
Brake fluid type DOT 4
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Rear brake caliper mounting bolt 22 2.2 16.0 )
Rear brake pad mounting pin 18 1.8 13.0 )
Pad pin plug 2.5 0.25 1.8 )
Rear brake caliper sliding pin 27 2.7 19.5 ) / )
Brake hose union bolt 23 2.3 16.5 )
Brake disc bolt 23 2.3 16.5 )

Suzuki GSF1200S Specifications

General

Displacement	1157 cc
Bore x Stroke	79.0 mm x 59.0 mm
Compression Ratio	9.5:1
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Front Suspension	Telescopic, coil spring, oil damped
Rear Brakes	Single hydraulic disc
Front Tire	120/70-ZR17
Rear Tire	180/55-ZR17
Overall Width	790 mm (31.1 in)
Seat Height	790 mm (31.1 in)
Lubrication	Wet sump
Final Drive	Chain
Starter	Electric
Engine Type	4-stroke, 4-cylinder, DOHC
Rear Suspension	Link-type, coil spring, oil damped
Front Brakes	Dual disc
Fuel Tank Capacity	20 liters
Rear Suspension Adjustability	Preload adjustable
Ground Clearance	135 mm
Overall Length	2, 130 mm
