5C-6 Clutch:
7) Close the air bleeder valve and disconnect a clear
hose.
8) Fill the reservoir with new fluid to the upper mark of
the reservoir.
9) Install the reservoir cap.
Tightening torque
Air bleeder valve (Clutch) (a): 8 N·m (0.8 kgf-m,
6.0 lb-ft)
Clutch Hose Removal and Installation
B649G15306012
Removal
1) Drain clutch fluid. Refer to “Clutch Fluid
Replacement: ”.
2) Remove the fuel tank. Refer to “Fuel Tank Removal
and Installation: in Section 1G”.
3) Remove the clutch hose as shown in the clutch hose
routing diagram. Refer to “Clutch Hose Routing
Diagram: ”.
Installation
1) Install the clutch hose as shown in the clutch hose
routing diagram. Refer to “Clutch Hose Routing
Diagram: ”.
2) Install the fuel tank. Refer to “Fuel Tank Removal
and Installation: in Section 1G”.
3) Bleed air from the clutch system. Refer to “Air
Bleeding from Clutch Fluid Circuit: ”.
(a)
I649G1530063-01

Suzuki GSF1200S Specifications

General

Displacement	1157 cc
Bore x Stroke	79.0 mm x 59.0 mm
Compression Ratio	9.5:1
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Front Suspension	Telescopic, coil spring, oil damped
Rear Brakes	Single hydraulic disc
Front Tire	120/70-ZR17
Rear Tire	180/55-ZR17
Overall Width	790 mm (31.1 in)
Seat Height	790 mm (31.1 in)
Lubrication	Wet sump
Final Drive	Chain
Starter	Electric
Engine Type	4-stroke, 4-cylinder, DOHC
Rear Suspension	Link-type, coil spring, oil damped
Front Brakes	Dual disc
Fuel Tank Capacity	20 liters
Rear Suspension Adjustability	Preload adjustable
Ground Clearance	135 mm
Overall Length	2, 130 mm
