Lighting Systems: 9B-13
Specifications
Service Data
B649G19207002
Wattage
Unit: W
Tightening Torque Specifications
B649G19207003
NOTE
The specified tightening torque is also described in the following.
“Rear Combination Light Construction: ”
“Reflex Refrector Construction (For E-24, 28): ”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque Specifications: in Section
0C”.
Special Tools and Equipment
Special Tool
B649G19208001
Item
Specification
GSF1200 GSF1200S
Headlight
HI 60 55
LO 55 55
Parking or position light 5 5 x 2
Brake light/Taillight 21/5 ←
Turn signal light 21 x 4 ←
License plate light 5 ←
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Rear combination light mounting bolt 2.0 0.2 1.5 )
09900–25008
Multi-circuit tester set
) / ) / ) / )

Suzuki GSF1200S Specifications

General

Displacement	1157 cc
Bore x Stroke	79.0 mm x 59.0 mm
Compression Ratio	9.5:1
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Front Suspension	Telescopic, coil spring, oil damped
Rear Brakes	Single hydraulic disc
Front Tire	120/70-ZR17
Rear Tire	180/55-ZR17
Overall Width	790 mm (31.1 in)
Seat Height	790 mm (31.1 in)
Lubrication	Wet sump
Final Drive	Chain
Starter	Electric
Engine Type	4-stroke, 4-cylinder, DOHC
Rear Suspension	Link-type, coil spring, oil damped
Front Brakes	Dual disc
Fuel Tank Capacity	20 liters
Rear Suspension Adjustability	Preload adjustable
Ground Clearance	135 mm
Overall Length	2, 130 mm
