Suzuki GSF1200S User Manual

Clutch: 5C-21
Specifications
Service Data
B649G15307004
Clutch
Unit: mm (in)
Oil
Tightening Torque Specifications
B649G15307005
NOTE
The specified tightening torque is also described in the following.
“Clutch Hose Routing Diagram: ”
“Clutch Control System Components: ”
“Clutch Components: ”
“Clutch Assembly Diagram: ”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque Specifications: in Section
0C”.
Item Standard Limit
Clutch drive plate thickness 2.92 – 3.08 (0.115 – 0.121) 2.62 (0.103)
Clutch drive plate claw width — 13.0 (0.51)
Clutch driven plate distortion — 0.10 (0.004)
Clutch spring free height — 3.1 (0.12)
Clutch master cylinder bore 14.000 – 14.043 (0.5511 – 0.5529) —
Clutch master cylinder piston diam 13.957 – 13.984 (0.5495 – 0.5506) —
Clutch release cylinder bore 38.18 – 38.23 (1.503 – 1.505) —
Clutch release cylinder piston diam 38.08 – 38.13 (1.500 – 1.501) —
Item Specification Note
Brake fluid type DOT 4
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Air bleeder valve (Clutch) 8 0.8 6.0 ) / )
Clutch master cylinder holder bolt 10 1.0 7.0 )
Clutch hose union bolt 23 2.3 16.5 )
Clutch lever pivot bolt 1.0 0.1 0.72 )
Clutch lever pivot bolt lock-nut 6.0 0.6 4.5 )
Clutch sleeve hub nut 150 15.0 108.5 )
