Swegon COMPACT Unit - Page 63

GB.COMPACTUT.170622
Registered design. The company reserves the right to make design changes without prior notice.
www.swegon.com 63
Function Factory-preset value Adjusted value
Flow/pressure
Fan Regulation, SA* X Flow Pressure Need Slave Flow Pressure Need Slave
Fan Regulation, EA* X Flow Pressure Need Slave Flow Pressure Need Slave
Flow, low speed* SA
1) 1)
EA
1) 1)
Flow, high speed* SA
2) 2)
EA
2) 2)
Flow, max speed SA
4) 3) 4)
EA
4) 3) 4)
Flow, min. speed SA
5)
EA
5)
Pressure, low speed* SA (Pa) 100
EA (Pa) 100
Pressure, high speed* SA (Pa) 200
EA (Pa) 200
Max. fan speed* SA (%) 100%
EA (%) 100%
Pressure, max speed * SA (Pa) 400
6)
EA (Pa) 400 6)
Demand-contr., low speed SA (%) 25
EA (%) 25
Demand-contr., high speed SA (%) 50
EA (%) 50
Clean Air Control
X Inactive Active Inactive Active
Outdoor temp. compen.
X Inactive Active Inactive Active
Flow
Winter compens. Y1 (%) 30
End point, winter X1 (°C) -20
Start. point, winter X2 (°C) 10
Down-speed regulation
Function
Inactive X SA SA + EA Inactive SA SA + EA
Neutral zone (°C) 0,0
In-operation
Time switch clock function X 1. Low – high 2. Stop – low – high 1. Low – high 2. Stop - low - high
Slave control
C-Factor 1,0
Filter function Inact. SA EA X SA+EA Inact. SA EA SA+EA
Prefilter X Inact. SA EA SA+EA Inact. SA EA SA+EA
Extended operation
External low speed (h:mm) 0:00
External low speed (h:mm) 0:00
* Not used for Clean Air Control
