Function Factory-preset value Adjusted value
Summer/winter time
Inactive X Active Inactive Active
Heating
Heat exchanger
Defrosting
X Inactive Active Inactive Active
Reheating
Exercising X Inact. Pump Valve P+V Inact. Pump Valve P+V
Exercise period 3 Min.
Interval 24 hrs.
"Heating BOOST"
Function, Off/On
X Inactive Active Inactive Active
Start limit, SA temp. (°C) 3,0
Ramp time (%) 2.5
Exercising Cooling relay 1 X Inact. Pump P+V Valve Inact. Pump P+V Valve
Cooling relay 2 X Inact. Pump P+V Valve Inact. Pump P+V Valve
Exercise period 3 Min.
Interval 24 hrs.
Control reaction speed
Step duration (s) 300
Outdoor temp. limit Step 1 (°C) 3,0
Step 2 (°C) 5,0
Step 3 (°C) 7,0
Reset time (s) 480
Cool. min. SA flow (m³s) 0,1
Cool. min. EA flow (m³s) 0,1
Neutral zone (°C) 2,0
"Cooling BOOST" X Inact. Comf. Econ. Sequ. Inact. Comf. Econ. Sequ.
Comf.+econ. Econ.+sequ. Comf.+econ. Econ.+sequ.
Start limit SA temp. (°C) 3,0
Ramp time (%) 2.5
Inputs/Outputs
Relay 1 A Alarm output 4)
Relay 2 B Alarm output 4)
Input 1 External low speed 5)
Input 2 External high speed 5)
"IQnomic Plus"
I/O Module No. 0 Input/Output
connections
X Inactive Active Inactive Active
I/O Module No. 3 Ext. monitoring
X Inactive Active Inactive Active
I/O Module No. 6 Ext. cooling
X Inactive Active Inactive Active
I/O Module No. 7 AYC
X Inactive Active Inactive Active
I/O Module No. 9 Preheating
X Inactive Active Inactive Active
Cooling
Cooling unit controls
Stepless
0-10 V
Stepless
10-0 V
On/off
1-step
On/off
2-step
On/off
3-step binary mode
Inactive Auto
operation
Inactive Auto
operation
X
X
Stepless
0-10 V
Stepless
10-0 V
On/off
1-step
On/off
2-step
On/off
3-step binary mode
