9.2.1.2 Supply Air Regulation
Supply air regulation involves keeping a constant supply
air temperature without consideration to the load in the
premises.
This type of regulation can be used when the load and
temperatures of the premises are predictable. In most
cases a reheating coil needs to be installed; possibly a
cooling coil as well.
The following settings can be entered at USER LEVEL un-
der TEMPERATURE/SETTINGS:
Value Setting Factory
range setting
Supply air temperature setpoint 15-40 °C 21.5 °C
Setting range for the setpoint is limited by Min. and Max.
settings at INSTALLATION LEVEL under HAND TERMINAL.
9.2.1.3 Extract Air Regulation
Extract air regulation involves keeping a constant tempe-
rature in the extract air duct (premises), by regulating the
supply air temperature. This provides a uniform tempera-
ture in the premises regardless of the load and this type
of regulation requires the installation of a reheating coil;
possibly a cooling coil as well.
The extract air temperature is measured by the tempera-
ture sensor inside the GOLD unit.
If this internal temperature sensor does not give an ad-
equate representative extract air temperature readings,
an external room temperature sensor can be installed and
wired to the control unit’s connection marked “Internal
Bus-1”.
The following settings can be entered at USER LEVEL un-
der TEMPERATURE/SETTINGS:
Value Setting Factory
range setting
Extract air-/room temp. setpoint 15-40 °C 21.5 °C
Min. Supply air temperature 13-18 °C 15 °C
Max. Supply air temperature 25-45 °C 28 °C
Setting range for the various values is limited by Min. and
Max. settings at INSTALLATION LEVEL under HAND TERMI-
NAL.
