Alarm No.:
Function
Factory preset value Adjusted value
Priority Indication Effect Priority Indication Effect
0=blocked LED 0=Operat. 0=blockedt LED 0=Operat.
A=A alarm 0=Off 1=Stop A=A alarm 0=Off 1=Stop
B=B alarm 1=On B=B alarm 1=On
1 External fire alarm tripped A**** 1 1*
2 Internal fire alarm tripped A**** 1 1*
3 Frost protection below alarm limit A**** 1 1*
4 R.hx. speed monitor tripped A 1 0**
5 Frost protection sensor defective A**** 1 1*
6 Supply air temp sensor defective A 1 1
7 Extract air temp sensor defective A 1 1
8 Outdoor air temp sensor defective B 1 0
9 No communication to r.hx. controller A *** 1 1
10 No communication to SA frequency conv. A *** 1 1
11 No communication to EA frequency conv. A *** 1 1
12 Over current in SA frequency conv. A *** 1 1
13 Over current in EA frequency conv. A *** 1 1
14 Under voltage in SA frequency conv. A *** 1 1
15 Under voltage in EA frequency conv. A *** 1 1
18 Excess temperature in SA frequency inverter A*** 1 1
19 Excess temperature in EA frequency inverter A*** 1 1
20 No communication SA frequency range
gateway A*** 1 1
21 No communication EA frequency range
gateway A*** 1 1
22 Hall sensor defective SA frequency range A*** 1 1
23 Hall sensor defective EA frequency range A*** 1 1
24 SA frequency range blocked A*** 1 1
25 EA frequency range blocked A*** 1 1
26 Start-up failure SA frequency range A*** 1 1
27 Over voltage in EA-2 frequency conv. A *** 1 1
30 Ext. EA/room temp sensor defective A *** 1 1
31 Ext. outdoor temp sensor defective B *** 1 0
34 Over current in r.hx. controller A *** 1 1
35 Under voltage in r.hx. controller A *** 1 1
36 Over voltage in r.hx. controller A *** 1 1
37 Over temperature in r.hx. controller A *** 1 1
38 R.hx pressure drop above alarm limit B *** 1 0
39 El.heating coil tripped A *** 1 1
40 Extract air temp below alarm limit A *** 1 1
41 Supply air temp below setpoint A *** 1 1
42 Ext.alarm No.1 tripped A*** 1 1
