Alarm No.:
Function
Factory preset value Adjusted value
Priority Indication Effect Priority Indication Effect
0=blocked LED 0=Operat. 0=blockedt LED 0=Operat.
A=A alarm 0=Off 1=Stop A=A alarm 0=Off 1=Stop
B=B alarm 1=On B=B alarm 1=On
43 Ext. alarm No.2 tripped B *** 1 0
44 SA duct pressure below setpoint B *** 1 0
45 EA duct pressure below setpoint B *** 1 0
46 SA duct pressure above setpoint B *** 1 0
47 EA duct pressure above setpoint B *** 1 0
48 Supply airflow below setpoint B *** 1 0
49 Extract airflow below setpoint B *** 1 0
50 Supply airflow above setpoint B *** 1 0
51 Extract airflow above setpoint B *** 1 0
52 Supply air filter dirty B *** 1 0
53 Extract air filter dirty B *** 1 0
54 Service period past alarm limit B *** 1 0
55 No comm. SA air flow pressure sensor A *** 1 1
56 No comm. EA air flow pressure sensor A *** 1 1
57 No comm. SA filter pressure sensor B *** 1 0
58 No comm. EA filter pressure sensor B *** 1 0
59 No comm. SA duct pressure sensor A *** 1 1
60 No comm. EA duct pressure sensor A *** 1 1
61 No comm. r.hx. pressure sensor B *** 1 0
62 No communication to I/O-module No:0 B *** 1 0
63 No communication to I/O-module No:1 B *** 1 0
64 No communication to I/O-module No:2 B *** 1 0
65 No communication to I/O-module No:3 B *** 1 0
66 No communication to I/O-module No:4 B *** 1 0
67 No communication to I/O-module No:5 B *** 1 0
68 No communication to I/O-module No:6 B *** 1 0
69 No communication to I/O-module No:7 B *** 1 0
70 No communication to I/O-module No:8 B *** 1 0
71 No communication to I/O-module No:9 B *** 1 0
72 No communication to main controller I/O A 1 1
75 Supply air humidity sensor faulty A *** 1 1
76 Extract air humidity sensor faulty A *** 1 1
83 Supply air, prefilter fouled. B*** 1 0
84 Exhaust air prefilter, fouled B*** 1 0
85 Cooling Output 1 tripped A 1 0
86 Cooling Output 2 tripped A 1 0
89 No comm. with press. sensor by SA prefilter B*** 1 0
