20.3 Electrical Data
20.3.1 Air Handling Unit
MIN. POWER SUPPLY
Size 05:
1-phase, 3-wire, 230 V -10/+15%, 50/60 Hz, 10 AT
Size 08:
3-phase, 5-wire, 400 V -10/+15%, 50/60 Hz, 10 AT
20.3.2 Fans
RATED DATA PER FAN
Size 05: 1 x 230 V, 50/60 Hz, 0.74 kW.
Size 08: 3 x 400 V, 50/60 Hz, 1.0 kW.
20.3.3 Electrical equipment cubicle
One 2-pole 3A Automatic circuit breaker for 230V control
current
20.3.4 Heat Exchanger Motor
Step motor, 3-phase, 5.8 A (2A)*, 50 V max 90 V.
*) The motor controls limit the output power to the value speci-
fied.
20.3.5 Control Inaccuracy
Temperature ± 1
o
C.
Airflow ± 5%.
