Electrical systems
62
3.3 12 Volt DC Fuses
WARNING: When replacing fuses always
replace a fuse with the correct value.
NEVER replace with a higher value / rating
as this could damage the wiring harness.
If a replacement fuse ‘blows’ do not keep
replacing the fuse as you could damage
the wiring harness. Please investigate the
fault and contact your dealer.
Fuse Rating Fuse Colour Description
1 20 Amps Yellow Motorhome Fridge
2 15 Amps Blue Motorhome Towing
3 7.5 Amps Brown Motorhome Marker Lights
4 15 Amps Blue Motorhome Fridge D+
5 10 Amps Red Fans
6 10 Amps Red 12V Sockets
7 10 Amps Red Front Internal Lights
8 10 Amps Red Water Pumps
9 15 Amps Blue Electric Step
10 10 Amps Red Motorhome Tank Heaters
11 10 Amps Red Auxiliary Supplies
12 5 Amps Tan Electronics
13 5 Amps Tan Ignitions
14 10 Amps Red Rear Internal Lights
15 25 Amps Clear Charger (fitted internally to PSU)
The following table shows the fuse allocation
for the 15 fuses fitted to the PSU. Please note
that fuses are dependant on PSU versions, so
not all fuses may be present.
