Equipment details
84
Turn on gas cylinder and open quick-acting
valve in the gas supply line.
Check whether the power supply fuse
protection on the camp site is adequate for the
900 W (3.9 A) or 1800 W (7.8 A) that have been
selected using the power selector switch.
The cable drum must be fully unwound in order
to prevent the power cable from overheating.
Summer operation (boiler operation only)
Select gas or electrical operation using the
power selector switch. Illumination of the
yellow LED (g) on the power selector switch
indicates that the unit is operating with 230 V.
Mixed operation (gas and electrical) is not
possible in summer mode. With this setting
the unit automatically selects electrical
operation with a preselected power setting of
900 W or 1800 W.
Move the rotary switch on the control panel to
position (I – summer operation) 40 °C or 60 °C.
The green (k) and yellow (p) LEDs light up.
When the selected water temperature is
reached (40 °C or 60 °C) the heater shuts off
and the yellow LED (p) goes off.
Winter operation
– Heating with water temperature monitoring
Select gas, electrical or mixed operation
using the power switch. Illumination of the
yellow LED (g) on the power selector switch
indicates that the unit is operating with
230 V.
Move rotary switch on control panel to
operating position (n).
Set the rotary switch (h) to the desired
thermostat setting (1 – 5). The green LED
(k) for operation is lit and simultaneously
indicates the position of the selected room
temperature. The yellow LED (p) indicates
the water‘s heat-up phase.
The device automatically selects the
required power setting in accordance with
the temperature difference between the
temperature selected on the control panel
and the current room temperature. When the
room temperature selected on the control
panel is reached, the heater switches back
to the smallest setting and heats the water
to 60 °C. Once the water temperature is
reached, the heater switches off and the
yellow LED (p) goes out.
The warm air fan can continue to run in
order to cool the unit (after-run).
– Heating without water temperature
monitoring
Select gas, electrical or mixed operation
using the power switch. Illumination of the
yellow LED (g) on the power selector switch
indicates that the unit is operating
with 230 V.
Move rotary switch on control panel to
operating position (m).
Turn the rotary switch (h) to the desired
thermostat setting (1 – 5). The green LED
(k) for operation is lit and simultaneously
indicates the position of the selected room
temperature. The yellow LED (p – water‘s
heat-up phase) will be lit only when the
water temperature is below 5 °C!
The device automatically selects the
required power setting in accordance with
the temperature difference between the
temperature selected on the control panel
and the current room temperature. Once
the room temperature selected on the
control panel has been reached, the heater
switches off. The warm air fan continues
to run at slow speed until the outgoing air
temperature (on the unit) has fallen to 40 °C
or less.
