SWM Superdual E4 2017 - Replacing the Number Plate Bulb; Tail Light

2
1
4
3
1
EN - 56
TAIL LIGHT
The tail light (1) is a LED light; Replace it when it does
not function.
REPLACING THE NUMBER PLATE BULB
- loosen screw (1) and remove the number plate
bulb (2) from the mudguard;
- take bulb holder (3) and bulb (4) out of the sup-
port;
- pull the bulb (4) to detach it from bulb holder.
Once the bulb has been replaced, reverse the above
procedure to reassemble.
