EN - 12
Fuel level indicator
- The graduated scale (1) indicates the fuel level in-
side the tank.
When the tank is full of fuel, all the sectors are
black.
When the fuel inside the tank reaches the reserve
level, the only sector that will remain black is sec-
tor (2), which will begin flashing; in this case, it is
recommended to refuel as soon as possible.
1- SPEED (kmh or mph) / ODO / FUEL
(figure 1)
- SPEED: 299 kmh or 299 mph;
- ODO: odometer- maximum value: 99999 km;
To replace kilometers with miles or miles with kilom-
eters proceed as follows:
1) set to gure 1, place the ignition key in the OFF
position and push the knob SCROLL (A);
2) place the ignition key in the ON position while
pressing the SCROLL wheel for 3 seconds (A)
To confirm the conversion, the “SET” and the Miles
and mph or km and kmh segment will activate for
3 seconds; afterwards the standard function in Fig.1
will reappear.
NOTE
After the previously described operation, the
ODO setting will be converted and all other
data reset (the H Counteris unchanged).
2- SPEED / H / FUEL (figure 2)
- SPEED: 299 kmh or 299 mph;
- H: shows the running hours of the engine (data
are saved in permanent memory every 10 min-
utes). Maximum value: 9999:59.
