3.4 Evacuating products of combustion
3.4.1 Models for indoor installation
Foruegasdischarge,refertoStandardsUNI7129-7131.Theuegas
exhaust/air intake kit is not supplied with the boiler as accessories for
sealed-chamber forced-draught appliances, which better adapt to the in
-
stallation context, can be used.
T
o extract the ue gases and restore the combustion air in the boiler,
use original piping or others with the same characteristics which are EC
certiedandensurethattheyarecorrectlyconnectedasindicatedinthe
instructionsprovidedwiththeuegasesaccessories.
Asingleuecanbeconnectedtoseveralappliancesprovidedthatevery
appliance is sealed chamber type.
TheboilerisatypeCappliance(withasealedchamber)andmustthere
-
fore
haveasecureconnectiontotheuegasesexhaustpipeandcom-
bustion
air intake pipewhich both owoutside, and without which the
appliance cannot operate.
“FORCED OPEN” INSTALLATION (B22-B52)
Theuegasexhaustpipecanbedirectedtothemostsuitabledirection
according to installation requirements.
For installation, follow the instructions supplied with the kit.
Inthisconguration,theapplianceisconnectedtotheø80mmuegas
exhaustpipebymeansofaø60-80mmadaptor(Fig.13).
b
Inthiscongurationthecombustionairiswithdrawnfromtheroom
where the appliance is installed, which should be technically suita-
ble and ventilated.
b
The non insulated ue gas outlet pipes are potential sources of
danger.
b
The table indicates the permitted linear lengths.
Model
Maximum length
Ø 80 mm (m)
Loss of load (m)
45° bend 90° bend
11 - 13 15 1,2 1,7
Models 11-13 Models 17
Fig. 13
COAXIAL DISCHARGES (60-100 Ø)
The boiler has been designed to be connected to concentric discharge/
suction pipes and with the opening for air suction (
D )closed(Fig.14).
Coaxialoutletscanbepointedinthedirectionmostsuitedtothespecic
installation room, in line with the lengths shown in the table.
For installation, follow the instructions supplied with the kit.
b
The table indicates the permitted linear lengths.
Horizontal
Model
Maximum length
Ø 60-100 mm (m)
Loss of load (m)
45° bend 90° bend
11 - 13 3,5 1 1,5
Vertical
Model
Maximum length
Ø 60-100 mm (m)
Loss of load (m)
45° bend 90° bend
11 - 13 4,5 1 1,5
Models 11-13 Models 17
112
117
D
D
D
D
Fig. 14
SPLIT PIPE OUTLETS (80 Ø)
Twin outlets can be placed in the most suitable direction according to the
room requirements.
The combustion air intake pipe must be chosen from the two inlets (
E and
F );removetheclosureplugxedwithscrewsandusethespecicadaptor
for the chosen input.
The air inlet adaptor Ø 80 (
E )mustbeorientedcorrectly,soitmustbe
xedwiththerelativescrews,sothatthepositioningtabdoesnotinterfere
with the casing.
b
The table indicates the permitted linear lengths.
Model
Maximum length
Ø 80 mm (m)
Loss of load (m)
45° bend 90° bend
11 - 13 15+15 1,2 1,7
