Chapter 4 Provisioning the TimeProvider
Provisioning the Outputs
Provisioning the Outputs
This section describes the commands you use to provision the outputs of the
TimeProvider.
Enabling and Disabling the Outputs
Use the ED-EQPT command to enable or disable the output signal. This command
affects the specified group of eight output channels, or sixteen output channels if the
Expansion panel is also used; individual channels cannot be enabled or disabled.
ED-EQPT:[<tid>]:<aid>:[<ctag>]::<keyword>=<value>;
This command has a default access level of ADMIN.
Sample Command
ED-EQPT::OUTA:TS1000::OUTSTATE=DISABLE;
This command disables output group A and turns off all eight channels, or sixteen
channels if the Expansion panel is also used.
Autonomous Message
TP-SSU 03-10-24 11-09-12
A 1189 REPT EVT
“OUTA,EQPT:NA,OUTSTATE,NSA,03-10-24 11-09-12:\"OUTPUT
GROUP STATE HAS CHANGED,DISABLE\””
;
Provisioning the Output Framing Type
Use the ED-SYNC command to provision the output framing type.
CAS is the only available option for E1 output framing because the BITS/SSU clock
in the TimeProvider generates the highest density ones signal available.
Downstream Network Elements (NEs) configured to receive CAS or CCS will accept
the CAS output generated by the TimeProvider without errors.
ED-SYNC:[<tid>]:<aid>:[<ctag>]::<keyword>=<value>;
<aid> <keyword> <value> Description Default value
OUTg
g = A | B | C | D
Select the output group
OUTSTATE ENABLE Enable the specified
output group
ENABLE
DISABLE Disable the specified
output group
To Next Page
