Chapter 5 Testing the TimeProvider
Testing the Outputs
Testing the Outputs
The TimeProvider supports up to 32 output signals on four output groups. You can
provision the output signal to the following types: 2M, CAS, D4, ESF, CC, JCC,
JCC4, 1.544 MHz, 6.312 MHz, 8 kHz, or ISOLATED_1.
To test the outputs, connect the communications analyzer to the output under test
and observe that the waveforms meet or exceed the specifications for that signal
type.
Test Record
Use Table 5-3 to record the results of the tests performed on the TimeProvider.
Table 5-3. Record of Test Results
Test Results (Pass/Fail) Date Initials
Verifying Normal Operation
IOC Operating Modes
Reference Switching
Non-Revertive Mode
Revertive Mode
Power Alarms
Input Errors
Local Serial Port
Remote Serial Port
Ethernet Port
Outputs
