Chapter 1 Overview of the TimeProvider
Physical Description
Figure 1-4. TimeProvider 1000 - Front Panel
Figure 1-5 illustrates the location of the connectors, cards, and modules in the
TimeProvider 1100.
Figure 1-5. TimeProvider 1100 - Rear Panel
Ethernet
Output Modules
IOC 2IOC 1 IMC
Power
Connector
Power
Connector
Input
Connector
Local Craft
Connector
Remote Serial
Connector
Expansion
Connector
GPS
Module
Connector
Ethernet
Output Modules
Power
Connector
Power
Connector
Input
Connector
Remote Serial
Connector
Expansion
Connector
GPS
Module
Connector
