Symmetricom TimeProvider 1100 User Manual

097-58001-02 Revision C – August 2005 TimeProvider User’s Guide 213
Index
G—I
firmware features 77
firmware, upgrading 181
first-time log-in 83
flow mode, setting 87
forced reference switching 102
frame type
inputs
102
outputs 111
FREEFLT keyword 113
free-run
and Retimer operation
113
free-run alarm, setting 121
free-run mode 29
frequency, input 101
front panel layout 26, 27
fuse, power supply 193
G
gate address 88
Global Services telephone/address 186
GPS
alarm codes
165
antenna location, setting 101
holdover 40
installing antenna 64–70
parameters, ED-EQPT command 100
setting parameters 100
GPS LED 147
GR-833 standard, date and time format 81
ground connections 54
grounding
cable length
54
chassis 54
H
handshake mode, setting 87
HOLDFLT keyword 113
holdover
and Retimer operation
113
GPS 40
holdover alarm, setting 121
Holdover LED 147
holdover mode 29
holdover mode, clock 29
I
IMC
alarm codes
164
data backup 131
diagnosing errors 152, 154
LEDs 152
overview 29
replacing 153
resetting 130
upgrading software 182
INIT-SYS command 130
in-process response, TL1 81
input
alarm codes
166
CAS, CCS 102
configuring frame type 102
default parameter values 203
disabling 99
enabling 99
frame type 102
frequency 101
LED, on IOC 147
overview 22
priority level 105
provisioning 99–108
PRR mode 96
QLEVEL 104
selecting 32
setting PM alarm thresholds 108
specifications 190
SSMs 38
SSU mode 24, 96
states 32
SUB mode 24, 96
input module
connecting to
57
installing 57
overview 29
replacing 155
input reference signals 32
in-service, IOC 98
installation
power connections
54
rack mounting 51
unpacking 50
installation check list 75
installing
antenna
64–70
change communication settings 73
Ethernet port connections 73
power connections 54
SynCraft 207
IOC
alarm codes
164, 165
data backup 131
input signals 32
LEDs 147
overview 29
reference inputs 32
removing 148–150
