Synesso MVP Technical Manual

22
HYDRAULIC SYSTEM
Pump conguraons:
MVP machines have the dual inlet conguraon, as shown above.
MVP Hydras have separate pumps and motors for each group. Hydra 3 Group is shown with Bypass Boxes
Pump and Motor:
Synesso™ uses a Fluid-o-Tech rotary
vane pump which boosts incoming
water pressure to 9 bar when the
motor is acvated. Pressure can be a
adjusted by loosening the nut on the
right side ng and then turning the
adjustment screw:
Clockwise - Increasing pressure
Counter-clockwise - Decreasing
Water to steam tank, Pink
Water to
brew tanks
Incoming water
Dual Inlet for MVP
Pressure Regulator - Pink
Water to steam tank
1st Group (Le)
Grey
2nd Group
(Center) Purple
3rd Group (Right)
Brown
MVP Hydra
