How to Replace Hard Disk Backplane for 8 bay/5 bay DiskStation
Page 21 of 39
Date: 2014/4/11
Issued by: Hardware Development Group, Synology
®
Inc.
Fig. 33 shows the status after the defective HDD backplane is removed from the
HDD chassis.
Fig. 33
HDD Chassis
Defective HDD Backplane
–
SATA Connector Side
