Synrad 32-1 - 32-1 Front Panel; 32-1 Rear Panel; Controls and Indicators

SYNRAD® 32-1 Operator’s Manual Version 2.2
28
Operation
Controls & Indicators
Controls and Indicators
32-1 front panel
Aperture Seal – prevents dust from damaging the output coupler during shipping. Remove
the red self-adhesive label before applying power to the laser.
Laser Exit Aperture – provides an opening from which the beam is emitted when lasing.
32-1 rear panel
The back panel is just a black plate.
Figure 3-1 Front panel controls and indicators.
Exit Aperture
Aperture Seal
