3.4 Switches
Four DIP-switches are available on the CAN-Ethernet Gateway for
configuration purposes of the device. Their function is described in the
following table:
Switch # Name Description
1 TERM Defines whether the CAN terminating resistor of
120 Ohm is active or not
ON Æ terminating resistor active/enabled
OFFÆ terminating resistor not active/disabled
2 DEFT Defines the start initialization of the CAN-Ethernet
Gateway (refer to section 3.5)
ON Æ factory default configuration will be loaded
OFFÆ user configuration will be loaded
3 BOOT Activate the “Bootstrap-Mode” of the CAN-Ethernet
Gateway (refer to section 8)
ON Æ “Bootstrap-Mode” will be entered
OFFÆ Firmware of the CAN-Ethernet Gateway starts
4 RES Reset the CAN-Ethernet Gateway (refer to section 8)
ON Æ Reset active/enabled
OFFÆ Reset not active/disabled
Table 5: Meaning of the Switches
