5 Gateway Configuration
5.1 Fundamentals
Configuration of the CAN-Ethernet Gateway can be accomplished in
two ways; using the RS-232 interface with a terminal program (refer
to section
3.5.2) or a Telnet connection over the Ethernet connection
(refer to section
3.5.3).
The CAN-Ethernet Gateway is configured via configuration scripts.
There are the following two configuration scripts:
/stdrc Standard configuration,
- it is fixed in the firmware;
- is executed if the switch "DEFT" is set to ON or if no
/save/rc exists
or if an error has been detected in the EEPROM or if a
firmware update has been performed
- it contains the following entries:
siocfg 9600
ipcfg 192.168.10.111 255.255.255.0
192.168.10.1
mkif led
/if/led0/fin +l +hd1
mkif can
mkif udpserv
mkif tcpserv
/if/can0 baud:0 canid:fe on
The CAN-Ethernet Gateway is in a passive state and
waits for connection queries following a start with the
standard configuration.
/save/rc customer specific configuration;
- can be established with the commands
write and sync
and is saved in EEPROM
- is executed if the switch "DEFT" is set to OFF
- is established by the customer based on the application
requirements
