CAN – Ethernet Gateway
14 © SYS TEC electronic GmbH 2007 L-1032e_9
3.5 Initial Setup and Operation
3.5.1 Standard Configuration
The CAN-Ethernet Gateway has the following standard (factory
default) configuration (Setting the Configuration Script, refer to
section
5.1):
Ethernet/Internet settings
IP address of the CAN-Ethernet Gateway: 192.168.10.111
Subnet- Mask: 255.255.255.0
Standard Gateway: 192.168.10.1
one UDP
2
server
one TCP server
CAN settings
CAN bit rate: 1 Mbit/s
CAN identifier for error messages: 0xFE
RS-232 interface
Baud rate: 9600 baud
Data bits: 8
Parity: none
Stop bits: 1
Protocol/flow control: hardware
2
BTP: Block Transfer Protocol for transmitting CAN messages via UDP/IP
