Name plate and type key |
13
6 Name plate and type key
Type: AXC 400-7/10°-2 (F)
Manufacturing order no.: 1002888063
Manufacturing date: 03/2017
Made in: Germany
Voltage: 230 / 400 V Y
Frequency: 50 Hz
Nominal power at shaft (P2): 0,75 kW
Current: 2,95 / 1,69 A
Insulation class: H
Enclosure class, motor: IP55
Fan impeller speed: 2850 1/min
Weight: 36 kg
Max. temperature of transported air: 55 °C - 400 °C/2h
Number of certificate: 0036-CPR-RG04-11
EN 12101-3 (2015)
Powered Smoke and Heat Control ventilator
Systemair GmbH - Seehöferstraße 45 - 97944 Boxberg - Germany
Values for the fan unit at optimal energy efficiency point,
determined without speed control:
η: 48,2 % Pitch angle: 14°
V: 11.105 m³/h psf: 574 Pa
P1: 3,67 kW RPM: 2940
Measurement cat. / Efficiency cat.: A / Static
Efficiency grade: (N38) N= 51,0
This Powered Smoke and Heat Control ventilator shall be installed as per the manufacturer's instruction.
Installation and Operating Instructions are within the delivery.
20
1
2
3
4
5
6
1
General data
2
Technical data
3
Temp./Time information/
only listed on smoke
extraction fans
4
ErP data
5
Certifications and QR—
Codes
6
Manufacturer Address
Table 6 Type key
AXC 400 -7
/10°* -2*
(-)(K), (B), (F)
-* —**
TR — Reversible
No sign — Uni-directional
-G – 2 fans in series
-B — Axial fan with insulated box
Temperature- Time information (smoke
extraction fan), see 5.1.5 Temperature types,
page 5
Number of poles
Blade angle
Number of blades
Nominal diameter of the fan
AXC
Axial fan
AXR
Axial fan — reversible
AJR
Circular jet fan
AJ8
Octagonal jet fan
*only AXC and AJ // **only AJR and AJ8
| 003
