SystemAir AXC Series User Manual

20
| Installation
Air gap AXC/AXR cont'd
630
+/– 1mm
625 mm 621 mm 615 mm
710
+/– 1mm
705 mm 701 mm 695 mm
800
+/– 1mm
795 mm 789 mm 783 mm
900
+/– 1mm
895 mm 889 mm 881 mm
1000
+/– 2mm
992 mm 988 mm 978 mm
1120
+/– 2mm
1112 mm 1105 mm 1095 mm
1250
+/– 2mm
1242 mm 1234 mm 1223 mm
1400
+/– 2mm
1386 mm 1383 mm 1370 mm
1600
+/– 3mm
1583 mm 1581 mm 1567 mm
7.8 Installation jet fans AJR, AJ8 and IV
Always install in a horizontal position.
7.8.1 Air gap
Ensure that the air gap between the housing and the impeller is complied with.
♦ Check if the air gap complies with the table.
♦ Do not install the fan if the gap in the table below is not complied with.
♦ Contact Systemair.
Table 12 Air gap
AJR/AJ8 (Standard temperature) AJR/AJ8
(K) + (B)
AJR/AJ8 (F)
Nominal
width
Housing tolerance
Rotor Ø Rotor Ø Rotor Ø
315
+/– 1 mm
312 mm 310 mm 306 mm
355
+/– 1 mm
352 mm 350 mm 346 mm
400
+/– 1 mm
397 mm 395 mm 391 mm
7.8.2 Deflector
For optimal guidance of the air current, a deflector made of galvanized steel sheet can be mounted on the pressure-
side silencer (accessory).
The deflector as accessory for AJR/AJ8 is delivered in a separate package.
♦ Before installing the jet fan, fasten the deflector on the silencer of the pressure side (see arrow).
♦ Position the deflector fins so that after fastening the jet fan to the ceiling, the air flow is directed downwards at a
10° angle. It may be possible to readjust the fans afterwards depending on the structures located in the immediate
vicinity, such as girders.
