| Electrical connection
Table 13 Motor protection
Type
Motor protection
Thermal protection,
standard
Speed regulation
AXC,-B,-D,-G,-P By customer PTC
Possible via frequency converter
AXC (B),(F),(K)
AXR (B),(F),(K)
By customer- must be
bypassed in case of fire
without (PTC optional)
Possible via frequency converter—
must be bypassed in case of fire
AXR By customer PTC
Possible via frequency converter
AXCBF By customer PTC
Possible via frequency converter
AJ8 (B), (K), (F)
AJR (B), (K), (F)
By customer- must be
bypassed in case of fire
without (PTC optional)
Possible via frequency converter—
must be bypassed in case of fire
AJ8
AJR
By customer PTC
Possible via frequency converter
8.4 Connection
♦ Check that the data on the name plate matches the connection data.
♦ Complete the electrical connection according to the circuit diagram.
♦ Lay the connection cables in the terminal box in such a way that allows the cover of the terminal box to be closed
without resistance.
♦ Use all of the locking screws.
♦ Insert the screws by hand to avoid damaging the thread.
♦ Tighten all glands well in order to guarantee protection class IP.
♦ Screw the lid of the terminal box/REV switch evenly tight.
♦ Connect the cable end in a dry environment!
Type
Electrical Connection
AXC,-B,-D,-G
Connection via terminal box. The terminal box is fitted on the outside of the housing.
AXR
Connection via terminal box. The terminal box is fitted on the outside of the housing.
AXC (B), (K), (F)
AXR (B), (K), (F)
Connection via terminal box. The terminal box is fitted on the outside of the housing.
AXCBF
Connection via terminal box. The terminal box is attached to the motor.
AJ8 (B), (K), (F)
AJR (B), (K), (F)
Connection via terminal box. The terminal box is fitted on the outside of the housing.
AJ8
AJR
Connection via terminal box. The terminal box is fitted on the outside of the housing.
