22
Acquaintance with the machine
Technical specifi-
cations
Dimensions / weight
Weight
Maximum weight (kg) 1,000
Length (m)
Overall length 4.55 (L)
Width (m)
Overall width with loading arm folded up and right wheel in transport position 2.45 (W
2
)
Overall width with loading arm folded up with both left and right wheel in transport position 2.18 (W
2
)
Overall width with loading arm folded down 3.75 (W
1
)
Height (m)
Overall height with loading arm folded up 2.28 (H)
H
L
W
1
W
2
